Diagnosis and prevalence of two new species of haplosporidians infecting shore crabs Carcinus maenas: Haplosporidium carcini n. sp., and H. cranc n. sp.

Published online by Cambridge University Press:  16 June 2020

Charlotte E. Davies
Affiliation:
Department of Biosciences, College of Science, Swansea University, SwanseaSA2 8PP, Wales, UK
David Bass
Affiliation:
Department of Life Sciences, The Natural History Museum, Cromwell Road, LondonSW7 5BD, UK Animal and Human Health, Centre for Environment, Fisheries and Aquaculture Science (CEFAS), Barrack Road, The Nothe, WeymouthDT4 8UB, UK
Georgia M. Ward
Affiliation:
Department of Life Sciences, The Natural History Museum, Cromwell Road, LondonSW7 5BD, UK
Frederico M. Batista
Affiliation:
Animal and Human Health, Centre for Environment, Fisheries and Aquaculture Science (CEFAS), Barrack Road, The Nothe, WeymouthDT4 8UB, UK
Sophie H. Malkin
Affiliation:
Department of Biosciences, College of Science, Swansea University, SwanseaSA2 8PP, Wales, UK
Jessica E. Thomas
Affiliation:
Department of Biosciences, College of Science, Swansea University, SwanseaSA2 8PP, Wales, UK
Kelly Bateman
Affiliation:
Animal and Human Health, Centre for Environment, Fisheries and Aquaculture Science (CEFAS), Barrack Road, The Nothe, WeymouthDT4 8UB, UK
Stephen W. Feist
Affiliation:
Animal and Human Health, Centre for Environment, Fisheries and Aquaculture Science (CEFAS), Barrack Road, The Nothe, WeymouthDT4 8UB, UK
Christopher J. Coates
Affiliation:
Department of Biosciences, College of Science, Swansea University, SwanseaSA2 8PP, Wales, UK
Andrew F. Rowley
Affiliation:
Department of Biosciences, College of Science, Swansea University, SwanseaSA2 8PP, Wales, UK
Rights & Permissions[Opens in a new window]

Abstract

This study provides a morphological and phylogenetic characterization of two novel species of the order Haplosporida (Haplosporidium carcini n. sp., and H. cranc n. sp.) infecting the common shore crab Carcinus maenas collected at one location in Swansea Bay, South Wales, UK. Both parasites were observed in the haemolymph, gills and hepatopancreas. The prevalence of clinical infections (i.e. parasites seen directly in fresh haemolymph preparations) was low, at ~1%, whereas subclinical levels, detected by polymerase chain reaction, were slightly higher at ~2%. Although no spores were found in any of the infected crabs examined histologically (n = 334), the morphology of monokaryotic and dikaryotic unicellular stages of the parasites enabled differentiation between the two new species. Phylogenetic analyses of the new species based on the small subunit (SSU) rDNA gene placed H. cranc in a clade of otherwise uncharacterized environmental sequences from marine samples, and H. carcini in a clade with other crustacean-associated lineages.

Type
Research Article
Creative Commons
Creative Common License - CCCreative Common License - BY
This is an Open Access article, distributed under the terms of the Creative Commons Attribution licence (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted re-use, distribution, and reproduction in any medium, provided the original work is properly cited.
Copyright
Copyright © The Author(s) 2020. Published by Cambridge University Press

Introduction

Haplosporidians (Rhizaria, Retaria, Ascetosporea, Haplosporida) are most often regarded as parasites of molluscs, the best known including Bonamia spp. in the flat oyster Ostrea edulis (Abollo et al., Reference Abollo, Ramilo, Casas, Comesaña, Cao, Carballal and Villalba2008), Haplosporidium nelsoni (MSX disease) and Haplosporidium costale (SSO disease) in both Crassostrea virginica and Crassostrea gigas (Burreson and Ford, Reference Burreson and Ford2004; Wang et al., Reference Wang, Lu, Liang and Wang2010), Minchinia spp. in various molluscs (Ramilo et al., Reference Ramilo, Abollo, Villalba and Carballal2017), and the hyperparasitic Urosporidium, which infects platyhelminth parasites of molluscs (Carballal et al., Reference Carballal, Díaz and Villalba2005), as well as free-living annelids (Caullery and Mesnil, Reference Caullery and Mesnil1905). Other species are known from a range of molluscan hosts, some causing disease and mortalities, others apparently persisting at low levels eliciting few clinical signs in their hosts – perhaps representing spill-over (Arzul and Carnegie, Reference Arzul and Carnegie2015; Ramilo et al., Reference Ramilo, Abollo, Villalba and Carballal2017; Ward et al., Reference Ward, Feist, Noguera, Marcos-López, Ross, Green, Urrutia and Bass2019).

More recently, Haplosporidium spp. have been identified as parasites of crustaceans, initially with the characterization of Haplosporidium littoralis in the shore crab Carcinus maenas (Stentiford et al., Reference Stentiford, Bateman, Stokes and Carnegie2013), and subsequently H. diporeae, H. echinogammari and H. orchestiae in amphipods (Winters and Faisal, Reference Winters and Faisal2014; Urrutia et al., Reference Urrutia, Bass, Ward, Ross, Bojko, Marigomez and Feist2019). Environmental sequencing (eDNA) studies show that many other haplosporidian lineages exist, associated with molluscan and crustacean (putative) hosts, and in the surrounding water, sediment and soil (Hartikainen et al., Reference Hartikainen, Ashford, Berney and Okamura2014; Ward et al., Reference Ward, Neuhauser, Groben, Ciaghi, Berney, Romac and Bass2018, Reference Ward, Feist, Noguera, Marcos-López, Ross, Green, Urrutia and Bass2019; Urrutia et al., Reference Urrutia, Bass, Ward, Ross, Bojko, Marigomez and Feist2019). However, crustaceans are generally overlooked as potential hosts of haplosporidians and ascetosporeans more widely (Bass et al., Reference Bass, Ward and Burki2019). A wider range of hosts is now being investigated using both eDNA and host survey approaches to better understand haplosporidian diversity, distribution, life cycles, contribution to ecological processes and disease connectivity. Because of these efforts, a much greater diversity of haplosporidian sequences has been revealed. Although most of the eDNA-generated sequences cannot be associated with specific hosts, the large number of sequences from disparate sample types allows the inference of ecological patterns such as habitat preference, temporal variation, possible alternative hosts and lifecycle stages. Additionally, the proliferation of genetic data (so far mostly 18S rRNA gene regions) provides much-needed material for phylogenetic reconstructions, which help to place characterized taxa into a more comprehensive evolutionary framework.

Integrating data from these different sources suggest that morphological variation within Haplosporida is not a very reliable indicator of phylogenetic affinities (Burreson and Reece, Reference Burreson and Reece2006). On the other hand, it should be clearly acknowledged that the 18S gene alone is insufficient to resolve many nodes on the haplosporidian phylogeny. As is the case for most other protistan groups, a robust phylogeny will likely only be possible based on more comprehensive taxonomic sampling approaches and a larger number of genes. Species definitions do not require unambiguous morphological differences between taxa, which is particularly challenging for protistan parasites as the full range of life stages cannot be accessed for study; free-living or dispersal stages are extremely elusive, and reproductive stages such as sporulation may not be present in all hosts in the lifecycle.

In this study, we describe two novel species of Haplosporida. Both species were found infecting shore crabs C. maenas collected from Mumbles Pier in Swansea Bay (South Wales, UK). We provide in-depth histological and phylogenetic information for novel species description.

Materials and methods

Survey site and sample collection

Shore crabs, Carcinus maenas, were sampled from the South Wales coast, UK at two distinct locations, the Prince of Wales Dock, Swansea (51°37′8.76″N, 3°55′36.84″W) and Mumbles Pier (51°34′8.958″N, 3°58′33.297″W) according to Davies et al. (Reference Davies, Batista, Malkin, Thomas, Bryan, Crocombe, Coates and Rowley2019). For 12 months from November 2017 to October 2018, the shore crab population was surveyed at both locations. Briefly, strings of baited traps were deployed and immersed for 24 h, retrieved and 50 crabs were chosen randomly, bagged individually and transported back to the laboratory on ice. All crabs were examined using haemolymph preparations for primary screening using the phase contrast optics of an Olympus BX41 microscope. If positive, polymerase chain reaction (PCR) and histology were then used as confirmatory measures. In addition to these clinical positives, a sub-sample of 324 animals were screened using PCR to account for any sub-clinical infections.

DNA extraction and quantification

Genomic crab DNA was extracted from 100 μL of thawed haemolymph using Qiagen Blood and Tissue Kits (Qiagen, Hilden, Germany) following the manufacturer's instructions. Extracted DNA was quantified using a Qubit® dsDNA High Sensitivity Assay Kit and Qubit® Fluorometer (Invitrogen, California, USA).

PCR and sequencing conditions

Initial haplosporidian-specific PCR reactions were carried out using a nested protocol modified from Hartikainen et al. (Reference Hartikainen, Ashford, Berney and Okamura2014), producing amplicons of ~670 bp. The first-round PCR (10 μL total reaction volume) used primers C5fHap and Sb1n and 1 μL template DNA (ca. 50–200 ng/μL) followed by a second round (25 μL total reaction volume) using primers V5fHapl and Sb2nHap and 2.5 μL amplicon DNA from first-round PCR. Both rounds of PCR used 2X Master Mix (New England Biolabs), oligonucleotide primers synthesized by Eurofins (Ebersberg, Germany), and were performed on a BioRad T100 PCR thermal cycler (primers and cycling conditions shown in Table 1). Products derived from the second round PCR were visualized on a 2% agarose/TBE gel with GreenSafe premium nucleic acid stain (NZYTech, Portugal). Sanger sequencing was performed using both forward and reverse primers synthesized by Source BioScience (Nottingham, UK) and Eurofins. Sequences were deposited in GenBank under accession numbers MN846346-MN8463561.

Table 1. Forward and reverse primer sequences used for the amplification of Haplosporidia by PCR. Each PCR run included initial denaturation and final extension steps, according to the first and final temperatures, respectively, noted in the thermocycler settings.

Each novel haplosporidian sequence type was extended to include the V2–V9 variable regions of the small subunit using primers HapGenFor33 (Ward et al., Reference Ward, Feist, Noguera, Marcos-López, Ross, Green, Urrutia and Bass2019) and Sb2nHap (Hartikainen et al., Reference Hartikainen, Ashford, Berney and Okamura2014). Reactions were performed in 50μL volumes comprising 1X Promega colourless buffer, 2.5 mm MgCl2, 0.4 mm dNTPs, 0.2 mg bovine serum albumin, 1.5 U GoTaq G2 (Promega, USA) and 2.5 μL template DNA. Resultant amplicons (ca. 1700 bp) were visualized on a 1% agarose-TAE gel stained with GelRed (Biotium, USA). and bidirectionally Sanger sequenced using the primers used for amplification. Sequences were deposited in GenBank under accession numbers MT311214 – MT311215.

Phylogenetic analyses

The two new near full-length small subunit sequences were blastn-searched against GenBank and the top 10 best matches downloaded. These 12 sequences were added to a phylogenetically comprehensive haplosporidian alignment using the L-ins-i algorithm in MAFFT (Katoh et al., Reference Katoh, Rozewicki and Yamada2017). The dataset was refined on the basis of this tree, resulting in an alignment of 50 sequences. Maximum Likelihood phylogenetic analyses were carried out using RAxML BlackBox v.8 (Stamatakis, Reference Stamatakis2014) (GTR model with CAT approximation; all parameters estimated from the data). A Bayesian consensus tree was constructed using MrBayes v.3.2.5 (Ronquist et al., Reference Ronquist, Teslenko, van der Mark, Ayres, Darling, Höhna, Larget, Liu, Suchard and Huelsenbeck2012). Two separate MC3 runs with randomly generated starting trees were carried out for 4 million generations each with 1 cold and 3 heated chains. The evolutionary model applied a GTR substitution matrix, a 4 category autocorrelated gamma correction and the covarion model. All parameters were estimated from the data. The trees were sampled every 1000 generations and the first 1 million generations discarded as burn-in. All phylogenetic analyses were carried out on the Cipres server (Miller et al., Reference Miller, Pfeiffer and Schwartz2010).

Histology

Tissue histology was used as the secondary tool after PCR, to estimate the severity of, and potential host immune responses to, any haplosporidian infection (e.g. melanisation reactions, haemocyte encapsulation). Three pairs of gills and three portions (ca.0.5 cm3) of the hepatopancreas/gonad were excised and fixed in Davidson's seawater fixative for 24 h prior to their storage in 70% ethanol. Samples were dehydrated in a graded series of ethanol, transferred to Histoclear/Histochoice (Sigma-Aldrich, Dorset, UK) and infiltrated with molten wax using a Shandon™ automated tissue processor (Thermo Fisher Scientific, Altrincham, UK) prior to embedding. Blocks were cut at 5–7 μ m thickness using an RM2245 microtome (Leica, Wetzlar, Germany). Sections were mounted on glass slides using glycerine albumin and stained with Cole's haematoxylin and eosin. Stained slides were viewed and imaged using an Olympus BX41 microscope. Images were adjusted for colour balance and contrast only.

Results

General population observations

Overall, 1,191 crabs were sampled across the year-long survey, 603 from the Dock and 588 from the Pier. Of these crabs, 10 individuals (0.84%) were seen to contain haplosporidians via haemolymph preparations of live cells viewed using phase-contrast microscopy, all in the Pier location. Following this, a subsample of 324 crabs was tested for haplosporidians via PCR. Of these further 324 crabs analysed using PCR, 6 crabs were positive for haplosporidians at a subclinical level (1.85%), again, all at the Pier location. In total, 334 crabs were tested for haplosporidians, first using haemolymph preparations observed using phase-contrast microscopy, then PCR and histology. Crabs harbouring haplosporidians occurred broadly across the whole year, showing no seasonality, in all months except January, May, July, August and November. There was also no apparent host sex preference (9 females vs 7 males).

Phylogenetic analyses

Partial 18S rRNA sequences of the crabs positive for haplosporidian by microscopical examination or group-specific PCR were aligned, showing two clearly distinct sequence types: Haplosporidium carcini sp. nov. and H. cranc sp. nov. Each crab harboured just one haplosporidian infection. These were searched using the BLASTn function against the NCBI GenBank nt database. The top match for H. carcini sp. nov was accession number MK070859 (87.7% identity, 95% coverage), which corresponds to a Mytilus edulis-infecting haplosporidian reported in Ward et al. (Reference Ward, Feist, Noguera, Marcos-López, Ross, Green, Urrutia and Bass2019). The closest characterized match for H. carcini sp. nov was Haplosporidium nelsoni, accession number U19538 (85.8% identity, 99% coverage). The top match for sequence H. cranc sp. nov was KF208557 (87.8%), a member of novel lineage A in Hartikainen et al. (Reference Hartikainen, Ashford, Berney and Okamura2014), sampled from seawater in the UK and Bulgaria. The top characterized match was Bonamia exitiosa (JF831802; 79.2%, 100% coverage).

Bayesian and Maximum Likelihood phylogenetic analyses (Fig. 1) revealed both H. carcini sp. nov. and H. cranc sp. nov. branch within the paraphyletic assemblage of lineages that currently comprise the genus Haplosporidium. Both sequence types were markedly different from characterized lineages in GenBank but more closely related to eDNA sequences derived from environmental and organismal samples. Haplosporidium carcini was 3.2% dissimilar to a sequence type detected in shore crab samples from the Dart and Tamar estuaries (SW England), and 8% dissimilar to one from amphipods also from the Tamar estuary, all forming a clade with 0.92 Bayesian Posterior Probability support. Haplosporidium cranc formed a maximally supported clade in the Bayesian analysis with two other lineages amplified from filtered water samples from the Fleet Lagoon (Weymouth, England), reported in Hartikainen et al. (Reference Hartikainen, Ashford, Berney and Okamura2014), and one from a finfish farm situated in an estuarine river in Borneo.

Fig. 1. Bayesian 18S rRNA gene phylogeny showing the positions of Haplosporidium carcini and H. cranc (bold text) in relation to a broad selection of other haplosporidians, rooted on Gromia and Filoreta. Bayesian Posterior Probabilities (BPP) and Maximum Likelihood (ML) bootstrap values are indicated on nodes; black filled circles indicate values of BPP ≥0.95 and ML bootstrap ≥95%.

Haplosporidium carcini sp. nov. and H. cranc sp. nov. were characterised from crabs Carcinus maenas sampled from one location, Mumbles Pier, Swansea Bay (51°34′8.958″N, 3°58′33.297″W); South Wales, UK.

Histopathology

Haplosporidium carcini: The haemolymph of crabs harbouring H. carcini infections was cloudy-milky in consistency. Observations of fresh haemolymph preparations with phase-contrast microscopy revealed a variable number of highly phase-refractile forms of this parasite. In the case of low severity infections (as judged by the numbers of parasites in the haemolymph preparations), there were small numbers of parasites with interspersed spread haemocytes (Fig. 2A) observed, while in high severity infections the haemolymph was replete with large numbers of parasites and an apparent marked reduction in haemocytes in such preparations (Fig. 2B). The severity of infection was assessed by observing parasite numbers in haemolymph and the apparent ratio of haemocytes to parasites. Thus, it is a qualitative observation only. Similarly, histology showed more parasites in tissues of heavily infected crabs. The majority of the haplosporidians in such preparations were found to be uni- and bi-nucleate of mean diameter 4.6 μ m (range 3.2–5.9 μ m, n = 20; Fig. 2C). Some infected crabs had a few multinucleate (range, 3–9 nuclei/plasmodium), plasmodia 11.3 μ m in diameter (range 6.8–14.1 μ m in diameter) present in the haemolymph (Fig. 2D). The haemolymph of all infected crabs also contained highly pleomorphic cells with blunt pseudopodial extensions that were morphologically distinct to the attached and spread haemocytes (Fig. 2E). The cytoplasm enclosed small (<1 μ m in diameter) phase-bright rounded particles apparently within vacuoles and elongate phase-dark bacteria-like structures (Fig. 2E). Whether these cells represent altered haemocytes or a stage of this or other parasites is unclear. There was no evidence of any uptake of this parasite morphotype by host haemocytes as no intracellular forms were observed. One of the 15 crabs affected by H. carcini was co-infected with a yeast-like fungus (Fig. 2F), two further crabs were co-infected with the dinoflagellate parasite, Hematodinium (not shown) and there were 4 crabs harbouring unidentified encysted trematode parasites in the hepatopancreas.

Fig. 2. Haplosporidium carcini. Phase-contrast micrographs of haemolymph preparations from infected shore crabs. (A). Apparent low-grade infection with adherent haemocytes (H) and non-adherent, refractile haplosporidia (unlabelled arrows). (B). Higher severity infection with numerous uninucleate parasites and smaller number of haemocytes (H). (C). Uni- and bi-nucleate (arrow) forms of parasite. (D). Multinucleated plasmodium. (E). Spread cells of unknown origin with cytoplasmic refractile bodies (*) and bacteria-like structures (arrow). (F). Coinfection of H. carcini (*) and an unidentified yeast-like fungus (Fu). Scale bars = 10 μ m.

Histological examination of crab tissues revealed the presence of both uninucleate and multinucleate plasmodia. Membrane formation around the nuclei is similar to that described in H. littoralis. In the case of the gills, numerous uninucleate forms were found in the haemal spaces and vessels within the central shaft and in the respiratory lamellae (Fig. 3A). There was no evidence of the uptake of such cells or breakdown products of these by the host's nephrocytes, epithelial cells underlying the cuticle or circulating haemocytes. Host response was limited to some haemocyte accumulation in haemal spaces in the hepatopancreas but with no evidence of walling-off of parasites. The interstitial spaces between the hepatopancreatic tubules were replete with uninucleate and multinucleate plasmodia (Fig. 3B and C). Both uninucleate and plasmodial stages were associated with the interstitial tissues surrounding the tubules. Uninucleate parasites were largely confined to haemal channels while plasmodia were found attached to the tubules and the fixed phagocytes within the inter-tubular space. Tubules themselves were not affected and no spore-like structures of H. carcini were observed in any infected tissues.

Fig. 3. Histopathology of Haplosporidium carcini infections in shore crabs. (A). Section through a gill lamella of a shore crab showing numerous uninucleate parasites (*) in the haemal spaces. (B). Low power micrograph of hepatopancreas from an infected crab. Note larger plasmodia (P) and small uninucleate forms of the parasite (unlabelled arrow) in the intertubular space. Tubule (Tu). (C). High power micrograph showing the presence of multinucleate plasmodia (P) and uninuclear forms (unlabelled arrows) in the intertubular space of a hepatopancreas. Note fixed phagocytes (FP) with no clear evidence of intracellular parasites. Scale bars = 10 μ m.

Haplosporidium cranc: One crab (0.30%) of the 334 surveyed crabs from the Pier location had a haplosporidian infection that showed distinct morphological differences to those of H. carcini. The haemolymph was milky in consistency and observations of haemolymph preparations revealed numerous mono-nucleated stages of the parasite with characteristic peripheral bands of chromatin (Fig. 4A). These cells were 8.7 μ m in diameter (range 5.9–11.4, n = 20). Histological examination of the crab with this infection showed numerous mononuclear forms of the parasite in all tissues (Fig. 4B). There were also plasmodial, multinucleate forms in the interstitial spaces of the hepatopancreas (Fig. 4C). There was no clear evidence of any forms of this parasite within free or fixed phagocytes and no spore-like structures were observed.

Fig. 4. Haplosporidium cranc infection of a shore crab. (A). Phase-contrast micrograph showing mononucleated haplosporidians in the haemolymph of an infected crab. Note unusual chromatin arrangement (unlabelled arrows). (B). Uninucleate haplosporidians in the terminal vessel of a gill lamella. Note prominent chromatin blocks in these cells (unlabelled arrow). (C). Multinucleated plasmodial forms (P) of this parasite in the interstitial space of the hepatopancreas. Scale bars = 10 μ m.

Taxonomic summary

Phylum: Retaria Cavalier-Smith (2018).

Class: Ascetosporea Cavalier-Smith (2002).

Order: Haplosporida Caullery and Mesnil (1899).

Family: Haplosporiidae Sprague (1979).

Genus: Haplosporidium Caullery and Mesnil (1899).

Species: Haplosporidium carcini sp. nov. Davies et al. (2020).

Diagnosis: Spherical monokaryotic and dikaryotic stages observed in haemolymph, with a mean diameter of 4.6 μ m (range 3.2–5.9 μ m). Plasmodia commonly found in connective tissue within the interstitial area of the hepatopancreas and rarely in the haemolymph mean diameter 11.3 μ m (range 6.8–14.1 μ m) with no more than 21 nuclei per section. Spore stages not observed but cannot be ruled out. Unusual pleomorphic cells were seen in haemolymph of infected crabs of unknown origin. Little host response to infection and no tissue damage apparent. No clear evidence of parasites within haemocytes or other cell types in the gills and hepatopancreas.

Type host: Shore crab (Carcinus maenas).

Type location: Mumbles Pier, Swansea Bay (51°34′8.958″N, 3°58′33.297″W)

Type material: Original slides used for this paper are stored together with biological material embedded in wax at Swansea University and the Cefas Weymouth Lab. The SSU rDNA sequence is deposited in GenBank under accession number MT311215.

Etymology: carcini = of the host genus Carcinus, in which this parasite was first detected.

Phylum: Retaria Cavalier-Smith (2018).

Class: Ascetosporea Cavalier-Smith (2002).

Order: Haplosporida Caullery and Mesnil (1899).

Family: Haplosporiidae Sprague (1979).

Genus: Haplosporidium Caullery and Mesnil (1899).

Species: Haplosporidium cranc sp. nov. Davies et al. (2020).

Diagnosis: Monokaryotic stages, 8.7 μ m in diameter (range 5.9–11.4 μ m) in haemolymph. Nuclei with peripheral bands of chromatin. Multinucleate plasmodia in gills and hepatopancreas. Spore stages not observed but cannot be ruled out. No evidence of host response to infection or tissue disruption.

Type host: Shore crab (Carcinus maenas).

Type location: Mumbles Pier, Swansea Bay (51°34′8.958″N, 3°58′33.297″W).

Type material: Original slides used for this paper are stored together with biological material embedded in wax at Swansea University and the Cefas Weymouth Lab. The SSU rDNA sequence is deposited in GenBank under accession number MT311214.

Etymology: cranc (Welsh) = crab

Discussion

Clear morphological differences were observed between the two new species, consistent with their disjunct branching positions in the phylogenetic analyses. Haplosporidium is well known to be a paraphyletic genus, and as more new sequence types are retrieved from infested animals and environmental sequencing studies, the more disunited lineages ascribable to the Haplosporidium become in the tree. It is clear that several new genera will be required once the necessary phenotypic data are available, and multi-gene trees will provide more insight into the branching order within the genus. Until such phylogenetic trees are available, attempts to determine the relationship between phylogeny and the subtle and multi-variate morphological differences between haplosporidian taxa are unlikely to be reliable, except at the highest level (for example between Bonamia and other haplosporidians).

Haplosporidian-like agents have been observed in crustaceans previously, e.g. in blue crabs Callinectes sapidus from North Carolina and Virginia, USA (Newman et al., Reference Newman, Johnson and Pauley1976) and in a mud crab Panopeus herbstii from Grand isle, Louisiana, USA (Sprague, Reference Sprague1963), however, these studies do not benefit from the molecular phylogenetic approach that we have used in the current study for shore crabs. More recently, environmental sequencing studies and investigations of crustacean hosts have shown that many haplosporidian lineages are associated with crustaceans. Urrutia et al. (Reference Urrutia, Bass, Ward, Ross, Bojko, Marigomez and Feist2019) described two new amphipod-infecting species of Haplosporidium, and revealed the diversity of crustacean-associated lineages across three diverse, but mostly poorly supported clades (consistent with the discussion above about the unsuitability of the 18S rRNA gene alone as a phylogenetic marker for haplosporidians). The two new species described here contribute further to our knowledge of crustacean parasites in this group. Haplosporidium carcini groups in Clade 1 of Urrutia et al. (Reference Urrutia, Bass, Ward, Ross, Bojko, Marigomez and Feist2019), near the amphipod parasite H. orchestiae and three other crustacean-associated lineages, detected by haplosporidian-specific PCR of DNA extracted from crustacean tissues or sterile seawater in which putative hosts were incubated to investigate their epi/endobionts. The exception in that clade is H. pinnae, which is an emerging pathogen of the critically endangered pen shell or fan mussel (Pinna nobilis) in the Mediterranean (Catanese et al., Reference Catanese, Grau, Valencia, Garcia-March, Vázquez-Luis, Alvarez, Deudero, Darriba, Carballal and Villalba2018). The co-clustering of parasite lineages with a diverse range of host affiliations may turn out to be commonplace in haplosporidians, but it remains a valid hypothesis that the pen shell parasite may also be a parasite of crustaceans or has undergone a switch in host preference. The haplosporidian Urosporidium crescens is a hyperparasite of the encysted metacercaria of the digenean Microphallus basodactylophallus that infects the blue crab (Callinectes sapidus). This haplosporidian does not infect the crab tissue but rather it hyperparasitizes the trematode (Perkins, Reference Perkins1971). Although unidentified encysted trematode parasites were found in the hepatopancreas of four H. carcini-infected crabs, there was no evidence of any hyperparasitization.

Haplosporidium cranc groups in a clade of uncharacterized environmental sequences from coastal marine and brackish habitats in the UK and a marine fish farm in Borneo. The relationship of this clade to other haplosporidians is very unclear, with no strong affinities to any other clade in the group. On current phylogenetic evidence alone, it could easily be considered a separate genus, but more phenotypic data are required before such a decision could be made.

Although the prevalence of infection by both species of novel haplosporidians was low, the severity of infection was high in over 50% of parasitised crabs examined. For example, the haemolymph of most crabs was replete with uninucleate stages of both species of parasites and there was evidence of reduced numbers of haemocytes in circulation (as judged by their relative scarcity in haemolymph preparations) presumably as a result of infection. The milky, or opaque haemolymph observed although not a characteristic of haplosporidian infections alone, was also noted by Stentiford et al. (Reference Stentiford, Bateman, Stokes and Carnegie2013) in their study with Haplosporidium littoralis in C. maenas. Furthermore, cloudy haemolymph is found in Hematodinium infected crabs (Davies et al., Reference Davies, Batista, Malkin, Thomas, Bryan, Crocombe, Coates and Rowley2019) and there is also a bacterial disease of shore crabs called milky disease, where the haemolymph is similarly opaque (Eddy et al., Reference Eddy, Powell, Gregory, Numan, Lightner, Dyson, Rowley and Shields2007). Hence, opaque haemolymph is not a unique characteristic of the current disease.

Despite the large numbers of parasites both in connective tissues around the hepatopancreatic tubules and in haemolymph, there was little clear evidence of any destruction or lysis of tissues as observed in other similar infections, including those caused by Haplosporidium raabei in zebra mussels Dreissena polymorpha (Molloy et al., Reference Molloy, Giamberini, Stokes, Burreson and Ovcharenko2012). Similarly, no stages of the parasites were observed infecting either free (i.e. circulating haemocytes) or fixed phagocytes in the gills and hepatopancreas unlike the observations of Stentiford et al. (Reference Stentiford, Bateman, Stokes and Carnegie2013) on H. littoralis infections in C. maenas. Deductions of intra- vs extra-cellular location of parasites can be difficult based on traditional histological methods alone and so we cannot fully rule out the possibility of intracellular development of these two novel haplosporidians. Furthermore, it is possible that these haplosporidians may replicate inside cell types in tissues not currently studied.

Many parasites and pathogens avoid or circumvent an immune response to aid in their invasion, therefore the lack of host response observed in our study was not an unusual finding. There are several examples of this phenomena in other infections within crustaceans. For instance, the dinoflagellate Hematodinium sp., a parasite of over 40 species of crustaceans, does not elicit any cellular host response (Rowley et al., Reference Rowley, Smith and Davies2015). Similarly, rickettsia-like bacteria also multiply in crabs inside fixed phagocytes in the hepatopancreas and hence can ‘hide’ away from the immune system (Eddy et al., Reference Eddy, Powell, Gregory, Numan, Lightner, Dyson, Rowley and Shields2007; Wang, Reference Wang2011).

The histopathology of these two new species shows distinguishing morphological characteristics. In particular, the nuclei in uninucleate and plasmodia of H. cranc contain highly unusual chromatin bands seen both in live cells examined with phase-contrast microscopy and fixed, haematoxylin-stained cells in solid tissues while these are absent in both H. carcini (this study) and H. littoralis (Stentiford et al., Reference Stentiford, Bateman, Stokes and Carnegie2013). Uninucleate forms in haemolymph are also less refractile than the equivalent stage in H. carcini. These features facilitate the rapid differentiation of these putative species based on morphology alone.

The presence of spore-like stages of both H. carcini and H. cranc was not observed in any of the tissues examined despite the acute nature of the infection as judged by the large numbers of parasites in the haemolymph. Similarly, Stentiford et al. (Reference Stentiford, Feist, Bateman and Hine2004, Reference Stentiford, Bateman, Stokes and Carnegie2013) noted this lack of an infective stage in H. littoralis infections in the same host species as the current study, and Urrutia et al. (Reference Urrutia, Bass, Ward, Ross, Bojko, Marigomez and Feist2019) also found no evidence of sporulation in two new haplosporidian parasites of amphipods. Urrutia et al. (Reference Urrutia, Bass, Ward, Ross, Bojko, Marigomez and Feist2019) suggested several reasons for this apparent lack of sporulating stages including the possibility that this event may occur in another host species. Shore crabs are scavengers and feed on a wide variety of dietary material such as dead fish and molluscs, including mussels (e.g. Cohen et al., Reference Cohen, Carlton and Fountain1995; Young and Elliott, Reference Young and Elliott2020) leaving them vulnerable to chance infections. Indeed, the recent finding of low level infections of shore crabs by the important viral pathogen of molluscs, Ostreid herpesvirus-1 microVar (Bookelaar et al., Reference Bookelaar, O'Reilly, Lynch and Culloty2018), may point to the possibility that C. maenas can act as a carrier, reservoir or alternate host for a range of parasites and pathogens because of their scavenging behaviour. The low prevalence of infections of C. maenas by these haplosporidians may also point to the presence of another definitive host in the intertidal zone where sporulation may occur.

Acknowledgements

The authors should like to thank Mr Peter Crocombe and Ms Emma Quinn for assistance in the laboratory and field.

Financial support

This study was part-funded by the European Regional Development fund through the Ireland Wales Cooperation Programme, BLUEFISH, awarded to AFR and CJC at Swansea University. AFR was also part-funded by the BBSRC/NERC ARCH UK Aquaculture Initiative (BB/P017215/1), and start-up funds from Swansea University assigned to CJC were used to supplement this study. Cefas funding was provided by the UK Department of Environment, Food and Rural Affairs (Defra) under contract FC1214 (to DB), FX003 (to KB), and FB002A (to SWF).

Conflict of interest

The authors declare that they have no conflict of interest.

Ethical standards

The authors assert that all procedures contributing to this work comply with the ethical standards of the relevant national and institutional guides on the care and use of laboratory animals.

References

Abollo, E, Ramilo, A, Casas, SM, Comesaña, P, Cao, A, Carballal, MJ and Villalba, A (2008) First detection of the protozoan parasite Bonamia Exitiosa (Haplosporidia) infecting flat oyster Ostrea edulis grown in European waters. Aquaculture 274, 201207.CrossRefGoogle Scholar
Arzul, I and Carnegie, RB (2015) New perspective on the haplosporidian parasites of molluscs. Journal of Invertebrate Pathology 131, 3242.CrossRefGoogle ScholarPubMed
Bass, D, Ward, GM and Burki, F (2019) Ascetosporea. Current Biology 29, R7R8.CrossRefGoogle ScholarPubMed
Bookelaar, BE, O'Reilly, AJ, Lynch, SA and Culloty, SC (2018) Role of the intertidal predatory shore crab Carcinus maenas in transmission dynamics of ostreid herpesvirus-1 microvariant. Diseases of Aquatic Organisms 130, 221233.CrossRefGoogle ScholarPubMed
Burreson, EM and Ford, SE (2004) A review of recent information on the Haplosporidia, with special reference to Haplosporidium nelsoni (MSX disease). Aquatic Living Resources 17, 499517.CrossRefGoogle Scholar
Burreson, EM and Reece, KS (2006) Spore Ornamentation of Haplosporidium nelsoni and Haplosporidium costale (Haplosporidia), and incongruence of molecular phylogeny and spore ornamentation in the haplosporidian. Journal of Parasitology 92, 12951301.CrossRefGoogle Scholar
Carballal, MJ, Díaz, S and Villalba, A (2005) Urosporidium sp. hyperparasite of the turbellarian Paravortex cardii in the cockle Cerastoderma edule. Journal of Invertebrate Pathology 90, 104107.CrossRefGoogle ScholarPubMed
Catanese, G, Grau, A, Valencia, JM, Garcia-March, JR, Vázquez-Luis, M, Alvarez, E, Deudero, S, Darriba, S, Carballal, MJ and Villalba, A (2018) Haplosporidium pinnae sp. nov., a haplosporidan parasite associated with mass mortalities of the fan mussel, Pinna nobilis, in the Western Mediterranean Sea. Journal of Invertebrate Pathology 157, 924.CrossRefGoogle ScholarPubMed
Caullery, M and Mesnil, F (1905) Sur quelques nouvelles haplosporidies d'Annélide. Comptes rendus des séances de la Société de Biologie 58, 580583.Google Scholar
Cohen, AN, Carlton, JT and Fountain, MC (1995) Introduction, dispersal and potential impacts of the green crab Carcinus maenas in San Francisco Bay, California. Marine Biology 122, 225237.Google Scholar
Davies, CE, Batista, FM, Malkin, SH, Thomas, JE, Bryan, CC, Crocombe, P, Coates, CJ and Rowley, AF (2019) Spatial and temporal disease dynamics of the parasite Hematodinium sp. in shore crabs, Carcinus maenas. Parasites & Vectors 12, 472.CrossRefGoogle ScholarPubMed
Eddy, F, Powell, A, Gregory, S, Numan, LM, Lightner, DV, Dyson, PJ, Rowley, AF and Shields, RJ (2007) A novel bacterial disease of the European shore crab, Carcinus maenas molecular pathology and epidemiology. Microbiology 153, 28392849.CrossRefGoogle ScholarPubMed
Hartikainen, H, Ashford, OS, Berney, C, Okamura, B, Feist SW, Baker-Austin C, Stentiford GD, Bass D et al. (2014) Lineage-specific molecular probing reveals novel diversity and ecological partitioning of haplosporidians. The ISME Journal: Multidisciplinary Journal of Microbial Ecology 8, 177186.CrossRefGoogle ScholarPubMed
Katoh, K, Rozewicki, J and Yamada, KD (2017) MAFFT Online service: multiple sequence alignment, interactive sequence choice and visualization. Briefings in Bioinformatics 20, 11601166.CrossRefGoogle Scholar
Miller, MA, Pfeiffer, W and Schwartz, T (2010) Creating the CIPRES science gateway for inference of large phylogenetic trees. In: Gateway Computing Environments Workshop, New Orleans. LA.CrossRefGoogle Scholar
Molloy, DP, Giamberini, L, Stokes, NA, Burreson, EM and Ovcharenko, MA (2012) Haplosporidium raabei n. sp (Haplosporidia): a parasite of zebra mussels, Dreissena polymorpha (Pallas, 1771). Parasitology 139, 463477.CrossRefGoogle Scholar
Newman, MW, Johnson, CA III and Pauley, GB (1976) A Minchinia-like haplosporidan parasitizing blue crabs, Callinectes sapidus. Journal of Invertebrate Pathology 27, 311315.CrossRefGoogle ScholarPubMed
Perkins, FO (1971) Sporulation in the trematode hyperparasite Urosporidium crescens De Turk, 1940 (Haplosporida: Haplosporidiidae): an electron microscope study. The Journal of Parasitology 57, 9.CrossRefGoogle Scholar
Ramilo, A, Abollo, E, Villalba, A and Carballal, MJ (2017) A Minchinia mercenariae-like parasite infects cockles Cerastoderma edule in Galicia (NW Spain). Journal of Fish Diseases 41, 4148.CrossRefGoogle Scholar
Ronquist, F, Teslenko, M, van der Mark, P, Ayres, DL, Darling, A, Höhna, S, Larget, B, Liu, L, Suchard, MA and Huelsenbeck, JP (2012) Mrbayes 3.2: efficient Bayesian phylogenetic inference and model choice across a large model space. Systematic Biology 61, 539542.CrossRefGoogle ScholarPubMed
Rowley, AF, Smith, AL and Davies, CE (2015) How does the dinoflagellate parasite Hematodinium outsmart the immune system of its crustacean hosts? PLoS Pathogens 11, e1004724.CrossRefGoogle ScholarPubMed
Sprague, V (1963) Minchinia louisiana n. sp. (Haplosporidia, Haplosporidiidae), a parasite of Panopeus herbstii. The Journal of Protozoology 10, 267274.CrossRefGoogle Scholar
Stamatakis, A (2014) RAxML version 8: a tool for phylogenetic analysis and post-analysis of large phylogenies. Bioinformatics (Oxford, England) 30, 13121313.CrossRefGoogle ScholarPubMed
Stentiford, GD, Feist, SW, Bateman, KS and Hine, PM (2004) Haemolymph parasite of the shore crab Carcinus maenas: pathology, ultrastructure and observations on crustacean haplosporidians. Diseases of Aquatic Organisms 59, 5768.CrossRefGoogle ScholarPubMed
Stentiford, GD, Bateman, KS, Stokes, NA and Carnegie, RB (2013) Haplosporidium littoralis sp. nov.: a crustacean pathogen within the Haplosporidia (Cercozoa, Ascetosprea). Diseases of Aquatic Organisms 105, 243252.CrossRefGoogle Scholar
Urrutia, A, Bass, D, Ward, GM, Ross, S, Bojko, J, Marigomez, I and Feist, SW (2019) Ultrastructural, phylogenetic and histopathological analysis of two novel haplosporidian parasites infecting amphipods reveals the importance of crustaceans as parasite hosts. Diseases of Aquatic Organisms 136, 87103.CrossRefGoogle Scholar
Wang, W (2011) Bacterial diseases of crabs: a review. Journal of Invertebrate Pathology 106, 1826.CrossRefGoogle ScholarPubMed
Wang, Z, Lu, X, Liang, Y and Wang, C (2010) Haplosporidium nelsoni and H. costale in the Pacific oyster Crassostrea gigas from China's coasts. Diseases of Aquatic Organisms 89, 223228.CrossRefGoogle ScholarPubMed
Ward, GM, Neuhauser, S, Groben, R, Ciaghi, S, Berney, C, Romac, S and Bass, D (2018) Environmental sequencing fills the gap between parasitic haplosporidians and free-living giant amoebae. Journal of Eukaryotic Microbiology 65, 574586.CrossRefGoogle Scholar
Ward, GM, Feist, SW, Noguera, P, Marcos-López, M, Ross, S, Green, M, Urrutia, A and Bass, D (2019) Detection and characterisation of haplosporidian parasites of the blue mussel Mytilus edulis, including description of the novel parasite Minchinia mytili n. sp. Diseases of Aquatic Organisms 133, 5768.CrossRefGoogle ScholarPubMed
Winters, AD and Faisal, M (2014) Molecular and ultrastructural characterization of Haplosporidium diporeiae n. sp., a parasite of Diporeia sp. (Amphipoda, Gammaridea) in the Laurentian Great Lakes (USA). Parasites and Vectors 7, 343.CrossRefGoogle Scholar
Young, AM and Elliott, JA (2020) Life history and population dynamics of green crabs (Carcinus maenas). Fishes 5, 4.CrossRefGoogle Scholar
Figure 0

Table 1. Forward and reverse primer sequences used for the amplification of Haplosporidia by PCR. Each PCR run included initial denaturation and final extension steps, according to the first and final temperatures, respectively, noted in the thermocycler settings.

Figure 1

Fig. 1. Bayesian 18S rRNA gene phylogeny showing the positions of Haplosporidium carcini and H. cranc (bold text) in relation to a broad selection of other haplosporidians, rooted on Gromia and Filoreta. Bayesian Posterior Probabilities (BPP) and Maximum Likelihood (ML) bootstrap values are indicated on nodes; black filled circles indicate values of BPP ≥0.95 and ML bootstrap ≥95%.

Figure 2

Fig. 2. Haplosporidium carcini. Phase-contrast micrographs of haemolymph preparations from infected shore crabs. (A). Apparent low-grade infection with adherent haemocytes (H) and non-adherent, refractile haplosporidia (unlabelled arrows). (B). Higher severity infection with numerous uninucleate parasites and smaller number of haemocytes (H). (C). Uni- and bi-nucleate (arrow) forms of parasite. (D). Multinucleated plasmodium. (E). Spread cells of unknown origin with cytoplasmic refractile bodies (*) and bacteria-like structures (arrow). (F). Coinfection of H. carcini (*) and an unidentified yeast-like fungus (Fu). Scale bars = 10 μm.

Figure 3

Fig. 3. Histopathology of Haplosporidium carcini infections in shore crabs. (A). Section through a gill lamella of a shore crab showing numerous uninucleate parasites (*) in the haemal spaces. (B). Low power micrograph of hepatopancreas from an infected crab. Note larger plasmodia (P) and small uninucleate forms of the parasite (unlabelled arrow) in the intertubular space. Tubule (Tu). (C). High power micrograph showing the presence of multinucleate plasmodia (P) and uninuclear forms (unlabelled arrows) in the intertubular space of a hepatopancreas. Note fixed phagocytes (FP) with no clear evidence of intracellular parasites. Scale bars = 10 μm.

Figure 4

Fig. 4. Haplosporidium cranc infection of a shore crab. (A). Phase-contrast micrograph showing mononucleated haplosporidians in the haemolymph of an infected crab. Note unusual chromatin arrangement (unlabelled arrows). (B). Uninucleate haplosporidians in the terminal vessel of a gill lamella. Note prominent chromatin blocks in these cells (unlabelled arrow). (C). Multinucleated plasmodial forms (P) of this parasite in the interstitial space of the hepatopancreas. Scale bars = 10 μm.
