Detecting schizophrenia at the level of the individual: relative diagnostic value of whole-brain images, connectome-wide functional connectivity and graph-based metrics

  • Du Lei (a1) (a2), Walter H. L. Pinaya (a2) (a3), Therese van Amelsvoort (a4), Machteld Marcelis (a4) (a5), Gary Donohoe (a6), David O. Mothersill (a6), Aiden Corvin (a7), Michael Gill (a7), Sandra Vieira (a2), Xiaoqi Huang (a1), Su Lui (a1), Cristina Scarpazza (a2) (a8), Jonathan Young (a2) (a9), Celso Arango (a10), Edward Bullmore (a11), Gong Qiyong (a1) (a12), Philip McGuire (a2) and Andrea Mechelli (a2)...

Abstract

Background

Previous studies using resting-state functional neuroimaging have revealed alterations in whole-brain images, connectome-wide functional connectivity and graph-based metrics in groups of patients with schizophrenia relative to groups of healthy controls. However, it is unclear which of these measures best captures the neural correlates of this disorder at the level of the individual patient.

Methods

Here we investigated the relative diagnostic value of these measures. A total of 295 patients with schizophrenia and 452 healthy controls were investigated using resting-state functional Magnetic Resonance Imaging at five research centres. Connectome-wide functional networks were constructed by thresholding correlation matrices of 90 brain regions, and their topological properties were analyzed using graph theory-based methods. Single-subject classification was performed using three machine learning (ML) approaches associated with varying degrees of complexity and abstraction, namely logistic regression, support vector machine and deep learning technology.

Results

Connectome-wide functional connectivity allowed single-subject classification of patients and controls with higher accuracy (average: 81%) than both whole-brain images (average: 53%) and graph-based metrics (average: 69%). Classification based on connectome-wide functional connectivity was driven by a distributed bilateral network including the thalamus and temporal regions.

Conclusion

These results were replicated across the three employed ML approaches. Connectome-wide functional connectivity permits differentiation of patients with schizophrenia from healthy controls at single-subject level with greater accuracy; this pattern of results is consistent with the ‘dysconnectivity hypothesis’ of schizophrenia, which states that the neural basis of the disorder is best understood in terms of system-level functional connectivity alterations.

  • View HTML
    • Send article to Kindle

      To send this article to your Kindle, first ensure no-reply@cambridge.org is added to your Approved Personal Document E-mail List under your Personal Document Settings on the Manage Your Content and Devices page of your Amazon account. Then enter the ‘name’ part of your Kindle email address below. Find out more about sending to your Kindle. Find out more about sending to your Kindle.

      Note you can select to send to either the @free.kindle.com or @kindle.com variations. ‘@free.kindle.com’ emails are free but can only be sent to your device when it is connected to wi-fi. ‘@kindle.com’ emails can be delivered even when you are not connected to wi-fi, but note that service fees apply.

      Find out more about the Kindle Personal Document Service.

      Detecting schizophrenia at the level of the individual: relative diagnostic value of whole-brain images, connectome-wide functional connectivity and graph-based metrics
      Available formats
      ×

      Send article to Dropbox

      To send this article to your Dropbox account, please select one or more formats and confirm that you agree to abide by our usage policies. If this is the first time you use this feature, you will be asked to authorise Cambridge Core to connect with your <service> account. Find out more about sending content to Dropbox.

      Detecting schizophrenia at the level of the individual: relative diagnostic value of whole-brain images, connectome-wide functional connectivity and graph-based metrics
      Available formats
      ×

      Send article to Google Drive

      To send this article to your Google Drive account, please select one or more formats and confirm that you agree to abide by our usage policies. If this is the first time you use this feature, you will be asked to authorise Cambridge Core to connect with your <service> account. Find out more about sending content to Google Drive.

      Detecting schizophrenia at the level of the individual: relative diagnostic value of whole-brain images, connectome-wide functional connectivity and graph-based metrics
      Available formats
      ×

Copyright

This is an Open Access article, distributed under the terms of the Creative Commons Attribution licence (http://creativecommons.org/licenses/by/4.0/), which permits unrestricted re-use, distribution, and reproduction in any medium, provided the original work is properly cited.

Corresponding author

Author for correspondence: Qiyong Gong, E-mail: qiyonggong@hmrrc.org.cn

References

Hide All
Anticevic, A, Haut, K, Murray, JD, Repovs, G, Yang, GJ, Diehl, C, McEwen, SC, Bearden, CE, Addington, J, Goodyear, B, Cadenhead, KS, Mirzakhanian, H, Cornblatt, BA, Olvet, D, Mathalon, DH, McGlashan, TH, Perkins, DO, Belger, A, Seidman, LJ, Tsuang, MT, van Erp, TG, Walker, EF, Hamann, S, Woods, SW, Qiu, M and Cannon, TD (2015) Association of thalamic dysconnectivity and conversion to psychosis in youth and young adults at elevated clinical risk. JAMA Psychiatry 72, 882891.
Biswal, BB, Mennes, M, Zuo, XN, Gohel, S, Kelly, C, Smith, SM, Beckmann, CF, Adelstein, JS, Buckner, RL, Colcombe, S, Dogonowski, AM, Ernst, M, Fair, D, Hampson, M, Hoptman, MJ, Hyde, JS, Kiviniemi, VJ, Kotter, R, Li, SJ, Lin, CP, Lowe, MJ, Mackay, C, Madden, DJ, Madsen, KH, Margulies, DS, Mayberg, HS, McMahon, K, Monk, CS, Mostofsky, SH, Nagel, BJ, Pekar, JJ, Peltier, SJ, Petersen, SE, Riedl, V, Rombouts, SA, Rypma, B, Schlaggar, BL, Schmidt, S, Seidler, RD, Siegle, GJ, Sorg, C, Teng, GJ, Veijola, J, Villringer, A, Walter, M, Wang, L, Weng, XC, Whitfield-Gabrieli, S, Williamson, P, Windischberger, C, Zang, YF, Zhang, HY, Castellanos, FX and Milham, MP (2010) Toward discovery science of human brain function. Proceedings of the National Academy of Sciences of the United States of America 107, 47344739.
Bullmore, ET and Bassett, DS (2011) Brain graphs: graphical models of the human brain connectome. Annual Review of Clinical Psychology 7, 113140.
Bullmore, E and Sporns, O (2009) Complex brain networks: graph theoretical analysis of structural and functional systems. Nature Reviews: Neuroscience 10, 186198.
Camchong, J, MacDonald, AW 3rd, Bell, C, Mueller, BA and Lim, KO (2011) Altered functional and anatomical connectivity in schizophrenia. Schizophrenia Bulletin 37, 640650.
Cetin, MS, Christensen, F, Abbott, CC, Stephen, JM, Mayer, AR, Canive, JM, Bustillo, JR, Pearlson, GD and Calhoun, VD (2014) Thalamus and posterior temporal lobe show greater inter-network connectivity at rest and across sensory paradigms in schizophrenia. Neuroimage 97, 117126.
Cheng, H, Newman, S, Goni, J, Kent, JS, Howell, J, Bolbecker, A, Puce, A, O'Donnell, BF and Hetrick, WP (2015) Nodal centrality of functional network in the differentiation of schizophrenia. Schizophrenia Research 168, 345352.
Drakesmith, M, Caeyenberghs, K, Dutt, A, Zammit, S, Evans, CJ, Reichenberg, A, Lewis, G, David, AS and Jones, DK (2015) Schizophrenia-like topological changes in the structural connectome of individuals with subclinical psychotic experiences. Human Brain Mapping 36, 26292643.
Fornito, A, Zalesky, A, Pantelis, C and Bullmore, ET (2012) Schizophrenia, neuroimaging and connectomics. Neuroimage 62, 22962314.
Fox, MD, Zhang, D, Snyder, AZ and Raichle, ME (2009) The global signal and observed anticorrelated resting state brain networks. Journal of Neurophysiology 101, 32703283.
Friston, K, Brown, HR, Siemerkus, J and Stephan, KE (2016) The dysconnection hypothesis (2016). Schizophrenia Research 176, 8394.
Golland, P and Fischl, B (2003) Permutation tests for classification: towards statistical significance in image-based studies. Information Processing in Medical Imaging 18, 330341.
Havaei, M, Davy, A, Warde-Farley, D, Biard, A, Courville, A, Bengio, Y, Pal, C, Jodoin, PM and Larochelle, H (2017) Brain tumor segmentation with deep neural networks. Medical Image Analysis 35, 1831.
He, Y, Chen, ZJ and Evans, AC (2007) Small-world anatomical networks in the human brain revealed by cortical thickness from MRI. Cerebral Cortex 17, 24072419.
Hu, ML, Zong, XF, Mann, JJ, Zheng, JJ, Liao, YH, Li, ZC, He, Y, Chen, XG and Tang, JS (2017) A review of the functional and anatomical default mode network in schizophrenia. Neuroscience Bulletin 33, 7384.
Iidaka, T (2015) Resting state functional magnetic resonance imaging and neural network classified autism and control. Cortex 63, 5567.
Khazaee, A, Ebrahimzadeh, A and Babajani-Feremi, A (2015) Identifying patients with Alzheimer's disease using resting-state fMRI and graph theory. Clinical Neurophysiology 126, 21322141.
Khazaee, A, Ebrahimzadeh, A and Babajani-Feremi, A (2016) Application of advanced machine learning methods on resting-state fMRI network for identification of mild cognitive impairment and Alzheimer's disease. Brain Imaging Behavior 10, 799817.
Kim, J, Calhoun, VD, Shim, E and Lee, JH (2016) Deep neural network with weight sparsity control and pre-training extracts hierarchical features and enhances classification performance: evidence from whole-brain resting-state functional connectivity patterns of schizophrenia. Neuroimage 124, 127146.
Kostro, D, Abdulkadir, A, Durr, A, Roos, R, Leavitt, BR, Johnson, H, Cash, D, Tabrizi, SJ, Scahill, RI, Ronneberger, O, Kloppel, S and Track, HDI (2014) Correction of inter-scanner and within-subject variance in structural MRI based automated diagnosing. Neuroimage 98, 405415.
Latora, V and Marchiori, M (2001) Efficient behavior of small-world networks. Physical Review Letters 87, 198701.
LeCun, Y, Bengio, Y and Hinton, G (2015) Deep learning. Nature 521, 436444.
Lei, D, Li, K, Li, L, Chen, F, Huang, X, Lui, S, Li, J, Bi, F and Gong, Q (2015) Disrupted functional brain connectome in patients with posttraumatic stress disorder. Radiology 276, 818827.
Lueken, U, Hilbert, K, Wittchen, HU, Reif, A and Hahn, T (2015) Diagnostic classification of specific phobia subtypes using structural MRI data: a machine-learning approach. Journal of Neural Transmission 122, 123134.
Lynall, ME, Bassett, DS, Kerwin, R, McKenna, PJ, Kitzbichler, M, Muller, U and Bullmore, E (2010) Functional connectivity and brain networks in schizophrenia. Journal of Neuroscience 30, 94779487.
Mwangi, B, Tian, TS and Soares, JC (2014) A review of feature reduction techniques in neuroimaging. Neuroinformatics 12, 229244.
Newman, ME (2003) Mixing patterns in networks. Physical Review. E: Statistical, Nonlinear, and Soft Matter Physics 67, 026126.
Nowak, I, Sabariego, C, Switaj, P and Anczewska, M (2016) Disability and recovery in schizophrenia: a systematic review of cognitive behavioral therapy interventions. BMC Psychiatry 16, 228.
Orrù, G, Pettersson-Yeo, W, Marquand, AF, Sartori, G and Mechelli, A (2012) Using Support Vector Machine to identify imaging biomarkers of neurological and psychiatric disease: a critical review. Neuroscience and Biobehavioral Reviews 36, 11401152.
Pettersson-Yeo, W, Allen, P, Benetti, S, McGuire, P and Mechelli, A (2011) Dysconnectivity in schizophrenia: where are we now? Neuroscience and Biobehavioral Reviews 35, 11101124.
Pettersson-Yeo, W, Benetti, S, Marquand, AF, Dell'acqua, F, Williams, SC, Allen, P, Prata, D, McGuire, P and Mechelli, A (2013) Using genetic, cognitive and multi-modal neuroimaging data to identify ultra-high-risk and first-episode psychosis at the individual level. Psychological Medicine 43, 25472562.
Pinaya, WH, Gadelha, A, Doyle, OM, Noto, C, Zugman, A, Cordeiro, Q, Jackowski, AP, Bressan, RA and Sato, JR (2016) Using deep belief network modelling to characterize differences in brain morphometry in schizophrenia. Scientific Reports 6, 38897.
Rajji, TK, Miranda, D and Mulsant, BH (2014) Cognition, function, and disability in patients with schizophrenia: a review of longitudinal studies. Canadian Journal of Psychiatry. Revue Canadienne de Psychiatrie 59, 1317.
Rehme, AK, Volz, LJ, Feis, DL, Bomilcar-Focke, I, Liebig, T, Eickhoff, SB, Fink, GR and Grefkes, C (2015) Identifying neuroimaging markers of motor disability in acute stroke by machine learning techniques. Cerebral Cortex 25, 30463056.
Rubinov, M and Bullmore, E (2013) Fledgling pathoconnectomics of psychiatric disorders. Trends in Cognitive Sciences 17, 641647.
Sabuncu, MR and Konukoglu, E and Alzheimer's Disease Neuroimaging Initiative (2015) Clinical prediction from structural brain MRI scans: a large-scale empirical study. Neuroinformatics 13, 3146.
Salvador, R, Suckling, J, Coleman, MR, Pickard, JD, Menon, D and Bullmore, E (2005) Neurophysiological architecture of functional magnetic resonance images of human brain. Cerebral Cortex 15, 13321342.
Shen, H, Wang, L, Liu, Y and Hu, D (2010) Discriminative analysis of resting-state functional connectivity patterns of schizophrenia using low dimensional embedding of fMRI. Neuroimage 49, 31103121.
Skatun, KC, Kaufmann, T, Doan, NT, Alnaes, D, Cordova-Palomera, A, Jonsson, EG, Fatouros-Bergman, H, Flyckt, L, KaSp, Melle, I, Andreassen, OA, Agartz, I and Westlye, LT (2017) Consistent functional connectivity alterations in schizophrenia Spectrum disorder: a multisite study. Schizophrenia Bulletin 43, 914924
Suo, X, Lei, D, Li, K, Chen, F, Li, F, Li, L, Huang, X, Lui, S, Li, L, Kemp, GJ and Gong, Q (2015) Disrupted brain network topology in pediatric posttraumatic stress disorder: a resting-state fMRI study. Human Brain Mapping 36, 36773686.
Suo, XS, Lei, DL, Li, LL, Li, WL, Dai, JD, Wang, SW, He, MH, Zhu, HZ, Kemp, GJK and Gong, QG (2018) Psychoradiological patterns of small-world properties and a systematic review of connectome studies of patients with 6 major psychiatric disorders. Journal of Psychiatry and Neuroscience 43, 427.
Vieira, S, Pinaya, WH and Mechelli, A (2017) Using deep learning to investigate the neuroimaging correlates of psychiatric and neurological disorders: methods and applications. Neuroscience and Biobehavioral Reviews 74, 5875.
Wang, J, Wang, X, Xia, M, Liao, X, Evans, A and He, Y (2015) GRETNA: a graph theoretical network analysis toolbox for imaging connectomics. Frontiers in Human Neuroscience 9, 386.
Watts, DJ and Strogatz, SH (1998) Collective dynamics of ‘small-world’ networks. Nature 393, 440442.
Wee, CY, Yap, PT, Denny, K, Browndyke, JN, Potter, GG, Welsh-Bohmer, KA, Wang, L and Shen, D (2012) Resting-state multi-spectrum functional connectivity networks for identification of MCI patients. PLoS One 7, e37828.
Wen, W, Zhu, W, He, Y, Kochan, NA, Reppermund, S, Slavin, MJ, Brodaty, H, Crawford, J, Xia, A and Sachdev, P (2011) Discrete neuroanatomical networks are associated with specific cognitive abilities in old age. Journal of Neuroscience 31, 12041212.
Woodward, ND and Heckers, S (2016) Mapping thalamocortical functional connectivity in chronic and early stages of psychotic disorders. Biological Psychiatry 79, 10161025.
Woodward, ND, Karbasforoushan, H and Heckers, S (2012) Thalamocortical dysconnectivity in schizophrenia. American Journal of Psychiatry 169, 10921099.
Xiao, B, Wang, S, Liu, J, Meng, T, He, Y and Luo, X (2017) Abnormalities of localized connectivity in schizophrenia patients and their unaffected relatives: a meta-analysis of resting-state functional magnetic resonance imaging studies. Neuropsychiatric Disease and Treatment 13, 467475.
Zhang, J, Wang, J, Wu, Q, Kuang, W, Huang, X, He, Y and Gong, Q (2011) Disrupted brain connectivity networks in drug-naive, first-episode major depressive disorder. Biological Psychiatry 70, 334342.
